Features:
Suitable for air or neutral gas.
Output: 0/2～10VDC,4～20mA, RS-485.
Used for accurate pressure and flow measurement for HVAC system.
Pressure range: as low as ±25Pa and as high as 0～± 2000Pa.
Accuracy: at room temperature, the static accuracy is within ±1.0% FS.
Temperature compensation: -10～+ 60 ℃, the thermal drift beyond the temperature compensation range is less than 0.05% FS / ℃.
High-performance pressure core, it has the characteristics of sensitive pressure response, stable long-term output, and excellent temperature performance.
Parameters:
Range | ±25Pa;±50Pa;±100Pa;±500Pa;±1000Pa;±2000Pa; 0～50Pa;0～100Pa;0～500P;0～1000Pa;0～2000Pa |
Precision | ±1.0%FS |
Output | 0/2～10VDC,4～20mA,RS-485 |
Power supply | 24VDC/24VAC |
Overload pressure | ×15 |
Operating temperature | -10～+60℃ |
Shell material | Industrial plastic, UL94-V0 |
Pressure connection | Metal Pagoda Head Interface, Ø6mm |
Certification | CE,FCC,RoHS |
