Features:
The left, right and depth sensing area of the sensor can be adjusted freely, the sensing is reliable, and the response time is<0.3 seconds.
Dual beam area sensing design ensures high efficiency and safety.
Easy installation, all settings can be realized by DIP switch and adjustment lever.
Engineering Applications:
The sensor is used to detect whether the fume hood is occupied, and cooperate with the VAV control system to switch the face velocity and working mode of the fume hood to achieve the goal of energy saving and emission reduction.
The sensor is used to detect whether the fume hood is occupied, and cooperates with the auto sash system to control the opening or closing of the sash to achieve the goals of safety, energy saving and emission reduction.
Parameters:
Induction method | Active infrared reflection |
Installation height | <3 meters |
Induction angle | Screw adjustment angle: ± 4 °,± 3.5 ° per division (far / near) |
Induction width | Screw adjustment angle: ± 7 °,± 3.5 ° per division (left / right) |
Power supply | 24VAC/24VDC |
Response time | <0.3 seconds |
Working temperature | -10～+60℃ |
Certification | CE,FCC,RoHS |
